Kink Carve Bike 2023
- SKU:
- bikecarve-GL
On Sale
Description
Kink Carve Bike 2023 16" Wheels
The Kink Carve 16” bike is the younger sibling of our Kicker 18”, and it ensures every age and every height rider can find a perfect fitting Kink bike. Kids are getting into BMX younger and younger, and we love it. The Kink Carve Bike 2023 comes in a great Gloss Digital White color, which is complimented by black components throughout.
Properly proportioned geometry and components create a modern, yet comfortable ride, suited for the rider who isn’t ready for the bump up to a larger 18” bike yet. Still stacked with great parts, the 2023 Carve comes with 7” Kink T700 bars, a short reach 40mm Mission topload stem, rock solid 3-piece tubular chromoly cranks with sealed Mid bottom bracket, a sealed integrated headset, and modern tread design 2.4” tires.
SPECIFICATIONS:
| Model Year | 2023 |
|---|---|
| Top Tube | 16.5 |
| Rear Triangle | 11.25" |
| Head Tube | 74.5 |
| Stand Over | 6.75" |
| BB Height | 9.75" |
| Frame | Carve |
| Material | Steel |
| Fork | Kink 16" Stryker Fork 4130 Chromoly Steerer Tapered Fork Legs |
| Fork Offset | 32mm |
| Compression Bolt Size | 24 |
| Handlebars | Kink T700 Bar 7" 100% Hi-Ten Steel |
| Bar Style | 2 Piece |
| Bar Rise | 7" |
| Grips | Mission Helix Mini Grips |
| Grip Style | Flangeless |
| Bar Ends | Mission Phase |
| Bar End Size | 31 |
| Stem | Mission Topload 40mm |
| Stem Style | Top Load |
| Stem Reach | 40mm |
| Headset | Mission Sealed Integrated (41.8 x 45) |
| Headset Style | Integrated |
| Brake Lever | Mission Mini |
| Lever Orientation | Right |
| Cable Type | Linear |
| Brakes | Mission Cease V2 |
| Frame Brake Style | Welded |
| Cranks | Mission Triumph 3pc Tubular Chromoly 140mm - 8 Spline |
| Crank Style | 3pc |
| Crank Length | 140mm |
| Drive Side Option | RHD |
| Spindle Size | 19mm |
| Spindle Splines | 8 |
| Bottom Bracket | Sealed Mid 19mm |
| Bottom Bracket Style | Mid |
| Pedals | Kink Hemlock Pedals |
| Pedal Size | 9/16" |
| Chain | Mission 410 |
| Chain Style | 410 |
| Sprocket | Mission Rank 25T |
| Sprocket Size | 25t |
| Hubs | Mission Covert Unsealed 3/8" Axle / Mission Function Semi-Sealed Cassette 14mm |
| Driver | 9 Tooth |
| Spoke Holes | 36 |
| Spoke Style | J Bend |
| Rims | Mission X7 / Mission X7 |
| Rim Wall | Single Wall |
| Wheel Size | 16" |
| Seat | Mission Cypress Mini Combo |
| Seat Style | Combo |
| Seat Post | Mission Combo Steel Post |
| Post Diameter | 25.4mm |
| Tires | Mission Tracker 16x2.4 |
| Bead Type | Wire |
| Tire Size | 16x2.4 |
| Valve Type | Schrader |
| Pegs | None |
For More Information See: Blackoutbmx.com
