Description
Chase Edge Pro XL BMX Bikes
The Chase Edge Pro XL BMX Bikes is our most sought after race bike for riders looking to get serious about BMX racing. With our 10 year history in offering complete bikes and our attention to detail, you know you are getting one of the best BMX bikes offered today! We build all our race bikes with our Championship winning geometry frames and then upgrade them with some of the top parts brands in BMX racing, such as Tioga, KMC, Insight and more. The Chase Edge will give you the edge over your competition and get on the way to #winwithChase
The 2023 Chase Edge Complete bike features a Disc Specific Race frame with Hydroformed & butted tubing, cable actuated disc brakes, integrated chain tensioner / disc brake mounting system, Tioga tires, Insight Chain Ring, Triple Clutch System cassette hub, KMC Chain, and a Pivotal Seat and Seat Post. With 10 bike sizes offered, the Edge line up gives you a full range of size options for just about any racer. The Chase BMX Racing brand is one of the Top BMX Racing Brands in terms of quality and customer service.
SPECIFICATIONS:
|
FRAME
|
CHASE Edge Pro XL 21″ Top Tube, 6061 T6 Alloy, Integrated 1-1/8″ Head Tube, Enclosed rear dropouts and Chain tensioner system |
|
FORK
|
CHASE Edge Pro Full Cr-mo, 1-1/8″ Steer Tube With Tapered Blades |
|
HEADSET
|
Integrated Sealed Bearing |
|
HANDLEBAR
|
CHASE Edge 22.2mm, 8.0″ Rise, 28″ Wide, 12° Back Sweep, 1° Up Sweep |
|
GRIPS
|
INSIGHT C.O.G.S 145mm Alloy Clamps Laser Etched Logo, PVC End Plug |
|
STEM
|
CHASE Edge 50mm 6061 T6 Alloy Laser Etched Logo |
|
BB
|
118mm Sealed Cartridge ISIS BB |
|
CHAINRING
|
INSIGHT 44 Tooth 4 Bolts 104mm 1/2″x3/32″ 5mm Alloy Ring |
|
CRANK
|
CHASE Edge 3 Piece Crank 180mm Alloy Arm With Laser Etched Logo, Cr-mo Chain Ring Bolts / Nuts |
|
PEDAL
|
Platform 9/16″ |
|
CHAIN
|
KMC Z1 narrow 1/2″x3/32″ |
|
COG
|
16 Tooth |
|
FRONT HUB
|
CHASE Edge Pro, 3/8″ Axle, 36H, Sealed Bearing |
|
REAR HUB
|
CHASE Edge Pro ISO, 3/8″ Axle, 36H, Sealed Bearing, Steel Cassette Body with 3 Pawls at Triple Angle Engagement for 24T Ratchets |
|
SPOKES
|
14 Gauge |
|
NIPPLES
|
Brass 14Gx5/8″ |
|
FRONT RIM
|
CHASE Edge 175 Double Wall 36H 20″x1.75″ Schrader Valve |
|
REAR RIM
|
CHASE Edge 175 Double Wall 36H 20″x1.75″ Schrader Valve |
|
FRONT TIRE
|
TIOGA PowerBand 20″x1.85″ |
|
REAR TIRE
|
TIOGA PowerBlock 20″x1.60″ |
|
TUBES
|
20″x1.50″-1.75″ Schrader Valve |
|
BRAKES
|
Mechanical disc caliper, linear-pull lever, 140mm disc rotor, Shimano B01S compatible pads |
|
SADDLE
|
CHASE Edge Pro Pivotal |
|
SEAT POST
|
Pivotal 27.2x250mm Alloy |
|
SEAT CLAMP
|
CHASE Edge QR Alloy 31.8mm |
For more information visit: chasebicycles.com
